SunGoldPower PowerWall X 48V 200Ah (51.2V, 10.24kWh)

★ Key Features

• 51.2V 200Ah (10.24kWh) LFP Battery
• IP65-Rated
• LCD Touchscreen Panel allows for real-time monitoring of vital information like state of charge, current, and voltage
• ≥ 8000 cycles @ 80% DOD
• 10-year Warranty
• Wall mount available (order SG48200T-WMKIT separately)

    ★ Parallel & Series Flexibility

• Parallel connection up to (32) units together, total parallel capacity of 328kWh
• Ideal for Residential and Commercial energy storage

    ★ Intelligent BMS

• Provides comprehensive protection to the battery from overcharging, discharging, over-current, short-circuits, and high-temperature cut-off

    ★ Communication

• Compatible with RS485 and CAN-Bus
• Compatible with major inverters including Growatt, Deye, SunGoldPower, Luxpower, Victron Energy, Schneider, EG4, Sol-Ark, Victron, Mppsolar, Megarevo, and others



Features

PowerWall X 51.2V 200Ah 10.24kWh LiFePO4 Battery

The PowerWall X was designed with maximum storage in mind. It can absorb energy from the sun all day for use at night, during a blackout, or in emergency situations.  With 10kWh of energy capacity, you can rest easy knowing your appliances will have the power they need.

Specifications



• Battery Type: LiFePO4 Battery
• Rated Voltage: 51.2V
• Rated Capacity: 200Ah
• Total Energy: 10.24kWh
• Max. Continuous Current: Charge140A, Discharge200A
• Recommended Charge Voltage: 56V
• Recommended Discharge Voltage: 48V
• Max. Short Current & Duration: 920A/300us
• Max Parallel number: 32 units
• Weight: 198.4 lbs
