Engineering Drawings (Residential & Consumer) – Stamped

SKU:

Stamped DWG (R&C)

Brand:

SKU:

Stamped DWG (R&C)

Brand:

Engineering

P.E. Stamped Engineering Drawing

For Residential & Consumer Applications

Electrical & Structural Options

Available for all 50 States

Price range: $1,200.00 through $1,500.00

Request a Bundle
Ordering more than one product?
Add items to your cart
and click "Request A Bundle"
to secure the best price possible!

PRICE MATCH GUARANTEE

Contact us if you found a better deal anywhere else! We’ll beat it!

Call Us

855-386-6669

Live Chat

100% US-based Support

Authorized
Dealer

Full Warranty &
Customer Service

Free
Shipping*

Available on
most items!

Best Pricing &
Product Support

Real Engineers.
Real Support.



EVONOMY Energy offers complete permit-ready Engineering Drawings with stamped electrical & structural certification options for all 50 states.

Why purchase Engineering Drawings?
  • Frequently required by AHJs (Authority Holding Jurisdiction), Utilities, Electricians, and building contractors. Very useful for DIY (Do-It-Yourself) installers which need professional support for their application.
  • When stamped, Engineering Drawings are legally liable, providing assurance of the design’s correctness and code compliance.
  • Unstamped Drawings also available (link)

What is included when purchasing Stamped Engineering Drawings?
  • Site Layout & Project Information Summary
  • Approved Equipment Summary (Solar Panels, Inverters, Batteries, Racking, Accessories, etc.)
  • Electrical Plan, Solar Attachment Plan
  • Line Diagram showing all connections
  • Design Tables
  • Placards
  • Assembly Details (for mounts & racking)
  • Resource Documents – Datasheets for core components
  • Licensed Professional Engineer Stamp

Additional information

Options

Stamped (Electrical), Stamped (Structural), Stamped (Electrical & Structural)
