Amensolar N3H-X12 12kW 48V Split-Phase Solar Inverter

SKU:

N3H-X12

Brand:

SKU:

N3H-X12

Brand:

Solar Inverter

12kW 48V Solar Inverter

200A Integrated Bypass

18kW Max PV Input (up to 500V)

UL1741SA, UL1699B, CSA 22.2

Original price was: $3,775.00.Current price is: $3,500.00.

Request a Bundle
Ordering more than one product?
Add items to your cart
and click "Request A Bundle"
to secure the best price possible!

PRICE MATCH GUARANTEE

Contact us if you found a better deal anywhere else! We’ll beat it!

Call Us

855-386-6669

Live Chat

100% US-based Support

Authorized
Dealer

Full Warranty &
Customer Service

Free
Shipping*

Available on
most items!

Best Pricing &
Product Support

Real Engineers.
Real Support.

★ All-In-One (AIO) Solar Hybrid Inverter
  • Split-Phase Inverter with 12kW output
  • (4) Integrated MPPTs supporting 16A (12 kW) each
  • Supports PV input sized up to 18kW @ 500V
  • 200A Grid Pass-through
  • Supports grid-tied (AC coupling) & off-grid system operation
  • Remote Monitoring over WiFi using SOLARMAN app or web portal
  • Integrated Rapid Shutdown (RSD) button
  • LCD Touch Panel
  ★ Parallel Function
  • Parallel up to (3) units together, supporting up to 36kW power output
  • 110-120/220-240V (Split-Phase) or 208V (2/3 Phase) or 230V (1-Phase)
  • 3+ units required for 3-Phase operation
  • Parallel function increases net inverter power and surge capacity.
  ★ (4) Charging Modes & (4) Output Modes
  • Charging Modes: AC Priority / Solar Priority / Only Solar / Grid & Solar Hybrid Charging
  • Output Modes: PV Priority / Utility Priority / Inverter Priority / Hybrid Output
  ★ Battery Compatibility
  • Voltage Range: 40-58V
  • Lithium and Lead Acid Battery
  • CAN & RS485 for supporting BMS communication
  description-img

Solar Hybrid Inverter Application

inverter-images

Product Highlights

  • The N3H-X12 hybrid inverter supports flexible application modes, including battery priority, peak shaving, and valley filling, as well as self-consumption, cater to various energy management requirements.
  • Supports 3 parallel connections including the simultaneous input of PV, batteries, diesel generators, power grids, and loads.
  • The color LCD provides users with configurable and easily accessible push button operation. with RS485/CAN port for battery communication.
  • Operates within an acceptable input voltage range of 120~500VAC.


Additional information

Weight 90.4 lbs
Dimensions 16.92 × 27.95 × 8.66 in

DATASHEET

USER MANUAL

Reviews

There are no reviews yet.

Only logged in customers who have purchased this product may leave a review.
